Product no.: 113 805 463
In stock
€32.49
All prices include VAT, plus Delivery charge

Product description:

support

Model/catalogue category:

The original Volkswagen exploded schematics are now also available in our new Classic Parts online-shop. You will find them by selecting your model. You can do this by using the vehicle search to restrict the model / model generation / model year / specification. You can find Volkswagen models made after 1998 by using the VIN. If you open the product detail page of a spare part, the button “to the plate” will be displayed under “model” / catalog assignment”. By clicking that button, it will take you directly to the appropriate exploded schematic for your Volkswagen.

Model Model year starting from Model year to
VW 1302/1303 1971 1980

Product details:

Product quality
Length 208 mm
Width 76 mm
Height 50 mm
Spare part number 113805463
Weight 0.5 KG

Delivery information:

Shipping Category: Package

The delivery time is approx 4-10 working days.
